Suporte retrátil OLICNC® HSK63A para fresadora CNC

Heat Shrink Fit Tool Holders Chucks Products Shrink fit tool holders Material Thermal expansion carburized steel Balance G2.5 25000rpm Model HSK63A / BT40 Available Optional accessories Shrink Fit Heating Machine Advantage 1.Shrink fit offers a very slim profile, which enables deep-reach-type applications like the in the die and mold industry 2. Shrink-fit tool holders grip the cutting tool 360 degrees around the shank. This prevents the cutting tool from moving during operations and controls the rigid connection. 3. Longer life. Hot loading and unloading operation, even if the same tool holder is hot loaded and unloaded more than 2000 times, the accuracy will not change.

  • Detalhes do produto

Heat Shrink Fit Tool Holders Chucks

Produtos
Shrink fit tool holders
Material
Thermal expansion carburized steel
Balance
G2.5 25000rpm
Modelo
HSK63A / BT40 Available
Optional accessories
Shrink Fit Heating Machine
Advantage
1.Shrink fit offers a very slim profile, which enables deep-reach-type applications like the in the die and mold industry
2. Shrink-fit tool holders grip the cutting tool 360 degrees around the shank. This prevents the cutting tool from moving during operations and controls the rigid connection.

3. Longer life. Hot loading and unloading operation, even if the same tool holder is hot loaded and unloaded more than 2000 times, the accuracy will not change.
